SUB WOOFERS

Pioneer Subwoofers

Pioneer S-21W



Add impact to your home cinema sound.



If you want to give your home listening and viewing experience some extra punch, the compact S-21W subwoofer is your solution for more bass.



Integrating a 100W RMS amplifier and enclosed with a ‘down-fire’ bass-reflex type cabinet, it ideally supports speaker configurations from 2.1 to 5.1.



Phase Control technology manages the time and phase response of the speakers to minimise the effect of additional sound delays usually due to the filtering process of multi-channel recordings.



  • Driver16cm cone woofer .
  • EnclosureFront Duct bass-reflex.
  • Line Input Sensitivity/Impedance (100 Hz)300 mV / 47 kΩ.
  • Frequency Range33 - 700 Hz.
  • Power Handling160W Peak / 100W RMS.
  • Dimensions (W x H x D)230 x 408 x 344 mm.
  • Weight6.5 kg.
  • Power RequirementsAC 220-240 V, 50/60 Hz .
  • Power Consumption (in use / standby)25w.

£129

Pioneer S-51W



Boost your home theatre.



Dedicated to music and movie lovers, the compact black S-51W subwoofer benefits from our technical know-how in designing both amplifiers and speakers.



It features a 20cm driver enclosed with a ‘down-fire’ bass-reflex type cabinet that inherits its stylish shape from our high-end Series 8 subwoofer.



Integrating a 150W RMS amplifier, it delivers enough power to support all speaker configurations from 2.1 to 7.1.



By complying with our Phase Control technology standards, it ensures a faithful reproduction of the original multi-channel source when combined with our AV receivers as they benefit from this proprietary technology.



Phase Control technology manages the time and phase response of the speakers to minimise the effect of additional sound delays usually due to the filtering process of multi-channel recordings.



  • Driver20cm cone woofer .
  • EnclosureBass-reflex cabinet .
  • Line Input Sensitivity/Impedance (100 Hz)190mV / 20kΩ .
  • Frequency Range26 - 900 Hz .
  • Power Handling150W .
  • Dimensions (W x H x D)360 x 382 x 360 .
  • Weight13.5 kg .
  • Power RequirementsAC 220-230 V, 50/60 Hz .
  • Power Consumption (in use / standby)130W / 0.45W

£229

Monitor Audio Subwoofers

Monitor Audio MRW-10



The muscular Monitor MRW-10 powered subwoofer delivers a thunderous bass down to below 30 Hz and offers a totally immersive movie, music, or gaming experience.



The Monitor MRW-10’s rigid cabinet is made from 18 mm thick MDF and accommodates a 10" long-throw MMP II bass driver and a rear port that allows optimal output from the powerful on-board 100 W class D power amplifier.



The Monitor MRW-10 boasts an array of features dedicated to optimising a home theatre system. There are three pre-set EQ mode settings (Music, Movie, Impact) to offer a level of adjustment for all rooms and tastes, and the controls use an advanced DSP based architecture to provide the ultimate in audio flexibility.



Specification



  • System Format Rear ported bass reflex cabinet
  • Lower Frequency Limit 30 Hz (-6 dB)
  • Upper Frequency LimitVariable 50 – 120 Hz @ 24 dB/Octave
  • Amplifier Output 100 W RMS
  • Amplifier Classification Class D with Switch mode PSU
  • Bass EQ Profiles Music / Movie / Impact
  • Phase Control 0 – 180°
  • Auto Sensing >3.5 mV
  • Input Level Requirements Standby after approximately 15 minutes if no signal sensed
  • Drive Unit Complement 1 x 10" MMP II long throw driver
  • Input Impedance >20 K ohms
  • Mains Input Voltage 110 – 120 Vac – 50 – 60 Hz 220 – 240 Vac – 50 – 60 Hz. Selectable
  • Fuse Specification 110 – 120 VAC – T4AL/250VAC 220 – 240 VAC – T4AL/250VAC
  • Connection 2 x Stereo RCA, 1 x LFE RCA connection 12 V trigger (3.5 mm mono mini-jack)
  • External Dimensions (Including Grille and Feet (H x W x D)) 336 x 320 x 350.6 mm
  • Standby Power Consumption <0.5 W standby
  • Weight 10.54 kg



£229





Monitor Audio Mass w200





The W200 is a powder keg for bass, primed with the precision-crafted ordinance of twin drivers and a potent 220W DSP controlled Class D amplifier.



It powers a side-firing 10” long throw C-CAM bass driver equipped with a huge, dual stack magnet system. Complementing the active driver is a 10” Auxiliary Bass Radiator (ABR), the two working in tandem to generate the output and scale normally associated with ported designs, but with the fast accurate transient response of a sealed box. Select ‘music’, ‘movie’ and ‘impact’ pre-set response curves using a back-panel switch.



Features:

  • C-CAM cone technology
  • 10” flat ABR (Auxiliary Bass Radiator)
  • Tuned for tight, fast bass punch
  • 220watt class-D power amplifier
  • DSP providing accurate filter characteristics
  • Advanced limiters designed to ensure the W200 never loses control.
  • 3 x pre-set bass modes (Music, Movie, Impact)
  • 12V trigger input – ensures W200 switches on and off with other equipment.
  • Heavy duty MDF construction
  • Discreet black cloth finish.

£299

Monitor Audio WS10



Complete with three-position EQ and a high quality digital wireless link to the ASB-10 sound bar, the WS-10 is a compact and versatile design, comprising an 8" C-CAM driver powered by a 120 watt amplifier, generously provisioned with individual volume and phase controls, and a standard array of wired LFE and 12V inputs for integration with an AVR in alternative system applications. For ever greater system design versatility, the WS-10 can connect wire-free to other systems via Monitor Audio’s new WT-1 transmitter module.



Equipped with twin HiVe reflex ports, the WS-10’s robust, low-profile cabinet of 18 mm MDF is designed with flexibility in mind, wirelessly extending the ASB-10’s full-range delivery and contributing deeper bass to any Soundbar or compact satellite system through wired or wireless connections from the widest range of discreet room locations: beneath furniture, along room boundaries or in corners.



Simple to set-up and integrate, flexible to use and expand, and easy to appreciate in any environment, Monitor Audio’s super-slim active ASB-10 Soundbar and its optional companion WS-10 active subwoofer employ over four decades of award-winning audio precision to help all home entertainment fans enjoy what they’ve been missing from their TVs and smartphones.



Technology



  • Wireless Active subwoofer
  • Class D-amplifier delivering 120 W
  • 8" long throw C-CAM bass mid-range driver
  • Compact dimensions for flexible room positioning flat against a wall, in corners, under furniture etc
  • 2.4 GHz receiver built-in for lossless/uncompressed audio reception in wireless applications.
  • Analogue LFE input
  • Volume and phase controls
  • Bass EQ settings optimised for music, movie or impact
  • 12 V trigger input (3.5 mm jack) to provide automatic switch on from AVR or other equipped amplifier
  • Power selection switch for auto standby or trigger
  • Rigid MDF construction with black sand vinyl finish
  • Dual HiVe port system
  • Dimensions H x W x D mm: 173 x 373 x 477 including feet

£299

Monitor Audio Bronze W10



All the audiophile-like transparency of New Bronze’s low-distortion design regimen concentrated in the bass domain.



This is new Bronze bass, deeply provisioned, authentically proportioned and dynamically fleet of foot, re-tooled from the ground up to punctuate the sound of every new Bronze system with stunningly natural bass transients, timed to perfection.



The sophisticated W10 subwoofer is a New Bronze original, featuring an exclusive trinity of uprated amplifier topology, powerful DSP processing and new long-throw driver design. Advanced switch-mode power conversion techniques, custom DSP tuning and a massive power reservoir combine to generate enormous dynamic headroom from the Class D power-pack, allowing the driver to drop low and punch hard without distortion for a truly sensational deep bass experience.



A down-firing 10" ABR (Auxiliary Bass Radiator) ensures that with the same compact footprint as its predecessor, the W10 delivers an incredible 6 dB greater SPL at 40 Hz. Choose how you enjoy the W10’s prodigious bass energy with pre-set EQ settings for music, movie or impact.





Technology

  • Ultra long throw 10" driver featuring concave ‘dished’ C-CAM cone
  • 10" flat panel ABR (auxiliary bass driver) mounted on the bottom to augment low frequency extension and power handling
  • Powerful Class-D Amplifier delivering over 200 W with low distortion
  • Switch Mode power supply, designed to deliver high continuous rating and provides the instantaneous delivery of high current when required
  • DSP processing with all control features and crossover performed in the digital domain
  • Three pre-set EQ mode settings (Music, Movie, Impact)
  • 12 volt trigger - provides switching control from AV amp, processor or home automation control system
  • 18 mm thick MDF construction
  • Heavy cabinet bracing applied to provide stiff, low resonance cabinet
  • Premium quality vinyl veneer finishes
  • The BXW-10 subwoofer represents a significant step up from its predecessor, the highly regarded BRW10. It's as compact as its forerunner, but more potent in every respect. A new 10" C-CAM® driver and 200 watt Class-D power amplifier have been devised in tandem to provide class leading standards of control, speed and punch. Featuring a new, fully integrated switch mode power supply, the new amplifier develops considerably more power than its predecessor, adding grip and clean bass delivery below 30Hz. A range of beautiful vinyl wood finishes provides the superlative looks to complement its accomplished deep bass performance.
  • Powerful compact active subwoofer.
  • 10" C-CAM® driver, 200W Class-D amplifier.
  • Available in four vinyl wood finishes.

£499

Monitor Audio Radius 380



The Radius 380’s twin side-firing 8" C-CAM drivers - one active and one passive ABR - work in tandem with a powerful 200 W cool-running Class D amplifier (double the power of its predecessor). The drivers have no grilles but are colour-coded to coordinate with cabinet finish. A 12 V trigger syncs the 380 with other AV components when the system is activated.





Technology



  • 18 mm MDF cabinet construction with internal bracing
  • Cool-running 200 W Class D amplifier with switch mode power supply (SMPSU)
  • Twin side-firing 8" C-CAM drivers - one active and one passive ABR
  • Low pass filter switch – for LFE or Stereo input selection
  • Power switch with ON – Auto- Off/ trigger settings
  • Stereo/ LFE RCA inputs
  • 3 x Pre-set EQ settings – Music/Movie/Impact
  • Available in real Walnut veneer, Gloss Black and Satin White
  • 5 year warranty

£499

Monitor Audio Radius 390



The Radius 390 comprises of colour-coded 10" C-CAM active/ABR drivers, powered by a 200 W Class D amplifier. Enjoy rapid EQ optimisation from Impact, Music and Movie settings, and system automation via the 12 V trigger.



Technology



  • 18 mm MDF cabinet construction with internal bracing
  • Cool-running 200 W Class D amplifier with switch mode power supply (SMPSU)
  • Twin side-firing 10" C-CAM drivers - one active and one passive ABR
  • Low pass filter switch – for LFE or Stereo input selection
  • Power switch with ON – Auto- Off/ trigger settings
  • Stereo/ LFE RCA inputs
  • 3 x Pre-set EQ settings – Music/Movie/Impact
  • Available in real Walnut veneer, Gloss Black and Satin White

  • 5 year warranty

£599

Monitor Audio CW8



The new CW8 places all the power in the hands of installer and client. Engineered for control in operation, bass quality and concealment in-room, the compact CW8 cube will add explosive bass frequencies to music and AV systems when tucked behind furniture on room boundaries.



Each little bass-engine is generously specified with custom installation in mind, providing versatile input and control options including RS232 and a dedicated ‘SubConnect’ PC applet via a wired USB interface.



The compact rigid 18 mm MDF cubic cabinets with regular 25.5 cm dimensions incorporate no fewer than three robust, similarly sized 8” C-CAM drivers. Each system array comprises an active high-excursion drive unit powered and trimmed by potent DSP-tuned amplification, together with twin side-mounted ABRs (Auxiliary Bass Radiators).



Technology



  • Ultra-compact ‘cube’ shape designs
  • Twin side-mounted ABRs for increased output and reduced distortion. Higher output than a sealed box and better control and zero air noise compared to a ported box
  • High excursion woofers featuring signature C-CAM cone technology
  • High-power Class-D amplifier delivering 400 watts
  • DSP processing –all functions performed in the digital domain for precise control
  • RS-232 for integration with system controllers
  • SubConnect’ PC Applet for full feature adjustment, installer set-up and firmware update using USB
  • LFE Balanced XLR and unbalanced RCA Inputs
  • Stereo RCA line level inputs
  • Phase switch (0-180 degrees)
  • 12 V trigger and auto signal sensing with timer control
  • 4 x pre-set equalisation optimised for music, movie, flat and impact with customisation through SubConnect Applet
  • Robust metal mesh grille on front woofer
  • Rigid MDF cabinet construction with durable vinyl finish
  • 5 year warranty

£599

Monitor Audio CW10





The new CW10 places all the power in the hands of installer and client. Engineered for control in operation, bass quality and concealment in-room, the compact CW10 cube will add explosive bass frequencies to music and AV systems when tucked behind furniture on room boundaries.



Each little bass-engine is generously specified with custom installation in mind, providing versatile input and control options including RS232 and a dedicated ‘SubConnect’ PC applet via a wired USB interface.



The compact rigid 18 mm MDF cubic cabinets with regular 30 cm dimensions incorporate no fewer than three robust, similarly sized 10" C-CAM drivers. Each system array comprises an active high-excursion drive unit powered and trimmed by potent DSP-tuned amplification, together with twin side-mounted ABRs (Auxiliary Bass Radiators).



  • System Format Active sub-woofer system – twin ABR. 18 mm MDF cabinet (CARB2 approved)
  • Lower Frequency Limit 32 Hz (-6 dB)
  • Amplifier Output 400 W RMS @ < 1% THD+N
  • Maximum SPL 105.8 dBA
  • Amplifier Classification Class D amplifier with Switch mode power supply (SMPSU)
  • Inputs Stereo RCA LFE (RCA) LFE Balanced (XLR)
  • EQ Flat/ Music/ Movie/ Impact
  • Phase Control 0 & 180 degrees
  • Auto Sensing LFE Input <2mV Auto wireless audio input signal detection
  • Auto Standby After approximately 15 minutes if no signal sensed Wireless audio source turned off
  • Drive Unit Complement 1 x 10" (250 mm) C-CAM long throw driver, 2 x 10" (250 mm) ABR
  • Input Impedance > 20 ohms
  • Mains Input Voltage 110 - 120 Vac / 220 - 240 Vac 50/60Hz (Manual Switch selection)
  • Dimensions (Including Feet (H x W x D)) 315 x 305 x 320 mm
  • Trigger Input 5 - 12 V via 3.5 mm mono mini-jack socket
  • Power Consumption Standby: < 0.5 W (ErP approved) Typical Idle: < 10 W Max Rated: 400w
  • Weight (unpacked) 12.64 kg
  • Warranty 5 years

£799

Monitor Audio Silver 12



The Monitor Audio Silver Series subwoofer delivers seismic bass right down to 22 Hz using a powerful, long throw 12-inch driver.



The Silver W-12’s over-specified driver assembly employs a hugely powerful magnet system and massive voice coil to deliver immense power from the compact sealed cabinet. A heavy-duty diecast basket not only holds the massive system rigidly together, but also assists thermal sinking to keep the driver cool.



For the Silver W-12 subwoofer Monitor Audio specified a 500-watt Class-D amplifier and power-supply module from highly-regarded amplifier specialist Hypex; this provides incredible headroom and utilises advanced switch-mode power conversion techniques. A powerful DSP has been employed to deliver the best performance and filter characteristics, while running the unique APC (Automatic Position Correction) system. The APC is a completely in-house development, designed to automatically correct for room modes. It uses a microphone and test tones to calculate detrimental room modes and correct frequency response, optimising it for the room and position. This is a simple and quick automated process that is a complete revelation to the installer and ensures the user can enjoy the subwoofer quality without positioning restrictions.



At the heart of the Silver W-12 lies a sophisticated 32-bit micro-controller, monitoring performance thousands of times per second, ensuring the system can deliver the best possible bass. It will never become over-driven or distorted, even at maximum power.



  • Technology Ultra long-throw 12-inch driver featuring ‘dished’ C-CAM cone
  • Triple suspension for ultimate linearity ensuring control at high power and excursions
  • Oversized black anodised 3-inch voice coil which provides high power-handling and low distortion
  • Powerful 500 W RMS Class-D amplifier with switching power supply provides instantaneous delivery of high current when required
  • DSP processing with all control features and crossover performed digitally
  • Automatic Position Correction plus automatic room setup feature using microphone for simple system optimisation
  • USB for firmware updates
  • Three preset EQ mode settings (Music, Movie, Impact)
  • Available in Black Ash, Walnut, Rosenut, Natural Oak, High Gloss Black & Satin White

from £999

Monitor Audio Gold W15



For lovers of deep and refined bass notes, the Gold W12 is a must-have addition to any speaker set-up. Every soundtrack is reinforced by the deep and balanced depth effortlessly delivered by our premium subwoofer.



All of the rumble and wallop of Hollywood’s most action-packed blockbusters is yours from the potent Gold W12 Subwoofer, in which a 12" (305 mm) long-throw driver is reinforced by a pair of Auxiliary Bass Radiators (ABR) and powered by 600 W of Class D amplification. The power and scale this combination are capable of generating can be felt just as easily as it can be heard, thanks to its prodigious 20 Hz bass extension.



Gold W12 has a number of fine-tuning options, and thanks to Monitor Audio’s Automatic Position Correction (APC) system, the subwoofer can work at its optimum no matter where it’s positioned. And this is no blunt instrument – Gold W12 is just as capable of delivering all the music and harmonic detail of a kettle drum to the earth-shattering power of a volcanic explosion.



Settings adjustment is provided by the innovative controller mounted on the cabinet top panel, or by using Monitor Audio’s proprietary ‘SubConnect’ software. The settings provide four fully configurable user pre-sets per input, including modes for; Flat/Music/Movie and Impact equaliser settings. Fine-tuning can be made by adjusting the frequency, slope, trim and equaliser filters for each pre-set. The Night Mode actively reduces the dynamic range of louder sections according to the level the listener desires.



£1749

SVS Performance Subwoofers

PB-2000 SUBWOOFER



Featuring Ultra Series technology, this ported subwoofer unleashes effortless, commanding bass down to 17 Hz with exceptional detail and musicality. Sets all the performance benchmarks for a subwoofer under £1,000.



Room-shaking power and unprecedented low frequency extension down to 17 Hz while remaining a musical and accurate subwoofer. Featuring Ultra Series technology, the PB-2000 is driven by an unshakable 12-inch driver and 500 watts RMS, 1,100 watts peak power Sledge STA-500D DSP amplifier



  • Premium black ash finish.
  • Protective non-resonant steel mesh grille.
  • Front-firing 12" driver.
  • Rear-mounted amplifier.
  • Screw-in rubber feet.
  • Robust Medium Density Fiberboard(MDF) cabinet construction.
  • Cabinet Dimensions: 20.9" (H) x 17.3" (W) x 23.2" (D) (without grille).
  • Overall Dimensions: 20.9" (H) x 17.3" (W) x 25.4" (D) (with grille).
  • Weight (unboxed): 65.6 pounds.
  • Shipped Dimensions: 30" (H) x 23" (W) x 27" (D).
  • Shipped Weight: 82 pounds (37 kg)

£849

PB-3000 SUBWOOFER



Reference Subwoofer Performance Hits New Lows.



Crushing output and extreme low frequency extension down to 16Hz without sacrificing accuracy and control, the PB-3000 is a standard bearer for bass performance at any price. All new 13-inch high-excursion SVS driver, sophisticated 800 watts RMS, 2,500+ watts peak Sledge STA-800D2 DSP amplifier and first ever dual port SVS cabinet design ensure effortless output at the deepest octaves without a hint of distortion. PB-3000 features two port tuning modes, each with individual response curves to achieve the most accurate in-room frequency response possible whether in sealed or standard mode. With massive output that extends far below the threshold of human hearing, where it can only be felt, the PB-3000 unleashes the full impact of every movie, bassline and low frequency effect without ever compromising.



  • Premium Black Ash
  • Protective non-resonant steel mesh grille
  • Front-firing 13 inch high-excursion SVS driver
  • Rear-mounted amplifier with Intelligent Control Interface (ICI)
  • Dual 3.5-inch ports
  • Screw-in rubber feet
  • Robust Medium Density Fiberboard (MDF) cabinet construction
  • Dimensions (w/ grille): 21.9” (557mm) H X 18.3” (465mm) W X 26” (660mm) D
  • Dimensions (without grille): 21.9” (557mm) H X 18.3” (465mm) W X 23.5” (596mm) D
  • Shipped Dimensions: 31.3” (795mm) H 23.1” (587mm) W X 26.5” (674mm) D
  • Weight (unboxed): 82.2 lbs. (37.3 kg)
  • Shipped Weight: 97 lbs. (44 kg)

£1549

PB-4000 SUBWOOFER



Staggering low-frequency output and subterranean deep bass extension down to 13Hz with an amazing degree of subtlety and finesse to thrill both action movie buffs and ardent audiophiles.



Thunderous low frequency output and extreme deep bass extension, with accuracy and control, the PB-4000 is a benchmark setting subwoofer on every level with unheard-of performance and features for even double the price. The sophisticated DSP amplifier creates three port tuning modes, each with individual response curves to achieve the most accurate in-room frequency response possible. With the PB-4000, it’s like having three subwoofers in one. Effortlessly powerful with bass that extends far below the threshold of human hearing, the PB-4000 creates a revelatory experience with every movie and music listening session.



  • Premium Black Ash and Piano Gloss Black finish options
    Protective non-resonant steel mesh grille
    Front-firing 13.5" driver
    Rear-mounted amplifier
    Screw-in rubber feet
    Robust Medium Density Fiberboard (MDF) cabinet construction

    Cabinet Dimensions (without grille): 23.4” (595mm) H X 20.5” (520mm) W X 27.7” (704mm) D
    Cabinet Dimensions (with grille): 23.4” (595mm) H X 20.5” (520mm) W X 30” (763mm) D
    Shipped Dimensions: 29.1” (738mm) H X 26” (661mm) W X 36” (915mm) D
    Weight (unboxed): 153.2 lbs. (69.5 kg)
    Shipped Weight: 172.4lbs (78.2kg)

£2249

Print Print | Sitemap
© midsat ltd
