IN-WALL 'ARCHITECTURAL' SPEAKERS

Monitor Audio W165



Incorporating a 6 1/2" MMP II bass driver with Monitor Audio’s signature C-CAMGold Dome tweeter to provide high performance sound, ease-of-drive, and wide frequency response and dispersion.



Optimum imaging and set-up are established via a pivoting tweeter and high-frequency (+3 dB / 0 dB /-3 dB) level adjustment.



  • Frequency Response 60 Hz – 25 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 88.5 dB
  • Maximum SPL 107.4 dBA
  • Power Handling (RMS) 65 W
  • Recommended Amplifier Requirements 20 – 65 W
  • Drive Unit Complement 6 1/2" MMP II cone bass driver 1" C-CAM pivoting Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB)
  • Overall Diameter (Including Grille) 370 x 250 mm (149/16 x 913/16")
  • Overall Depth (Including Grille) 96 mm (33/4")
  • Mounting Depth 92 mm (35/8")
  • Cut-Out Hole Diameter 332 x 213 mm (131/16 x 83/8")
  • Fixing Type 6 position Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 2.21 kg (4 lb 14 oz)
  • Optional Pre-Construction Bracket WB6 (Purple)

£129 each

Monitor Audio W180





Incorporating an 8-inch MMP II bass driver with Monitor Audio’s signature C-CAMGold Dome tweeter to provide high performance sound, ease-of-drive, and wide frequency response and dispersion.



Optimum imaging and set-up are established via a pivoting tweeter and high-frequency (+3 dB / 0 dB /-3 dB) level adjustment.



Specification



  • Frequency Response 50 Hz – 25 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 90 dB
  • Maximum SPL 111.6 dBA
  • Power Handling (RMS) 120 W
  • Recommended Amplifier Requirements 30 – 120 W
  • Drive Unit Complement 8" MMP II cone bass driver 1" C-CAM Gold Dome tweeter Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB)
  • Overall Diameter (Including Grille) 441 x 288 mm (173/8 x 115/16")
  • Overall Depth (Including Grille) 104 mm (41/8")
  • Mounting Depth 100 mm (315/16")
  • Cut-Out Hole Diameter 387 x 234 mm (151/4" x 93/16")
  • Fixing Type 6 position Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 3.08 kg (6 lb 12 oz)
  • Optional Pre-Construction Bracket WB8 (Green)

£159 each

Monitor Audio W265



A 6 1/2 inch C-CAM bass driver and a more highly specified version of the C-CAM Gold Dome tweeter offer an extended high-frequency response to 30 kHz, as well as higher output and power handling capacity.



Optimum imaging and set-up are established via a pivoting tweeter, high frequency (+3 dB / 0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.



Specification



  • Frequency Response 55 Hz – 30 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 88.5 dB
  • Maximum SPL 107.4 dBA
  • Power Handling (RMS) 65 W
  • Recommended Amplifier Requirements 20 – 65 W
  • Drive Unit Complement 6 1/2"  C-CAM cone bass driver 1" C-CAM pivoting Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3dB / 0dB / -3dB) Boundary Compensation Switch
  • Overall Diameter (Including Grille) 370 x 250 mm (149/16 x 913/16")
  • Overall Depth (Including Grille) 96 mm (33/4")
  • Mounting Depth 92 mm (35/8")
  • Cut-Out Hole Diameter 332 x 213 mm (131/16" x 83/8")
  • Fixing Type 6 position Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 2.26 kg (5 lb)
  • Optional Pre-Construction Bracket WB6 (Purple)

£179 each

Monitor Audio W280



An 8-inch C-CAM bass driver and a more highly specified version of the C-CAM Gold Dome tweeter offer an extended high-frequency response to 30 kHz, as well as higher output and power handling capacity.



Optimum imaging and set-up are established via a pivoting tweeter, high frequency (+3 dB / 0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.



Specification



  • Frequency Response 45 Hz – 30 KHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 90 dB
  • Maximum SPL 111.6 dBA
  • Power Handling (RMS) 120 W
  • Recommended Amplifier Requirements 30 – 120 W
  • Drive Unit Complement 1 x 8" C-CAM cone bass driver 1 x 1" C-CAM Pivoting Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB) Boundary Compensation Switch
  • Overall Diameter (Including Grille) 441 x 288 mm (173/8 x 115/16")
  • Overall Depth (Including Grille) 104 mm (41/8")
  • Mounting Depth 100 mm (315/16")
  • Cut-Out Hole Diameter 387 x 234 mm (151/4 x 93/16")
  • Fixing Type 6 position Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 3.1 kg (6.8 lb)
  • Optional Pre-Construction Bracket WB8 (Green)

£210 each

Monitor Audio W280-IDC



Features an 8-inch C-CAM bass driver and a pivoting IDC module, housing a 4-inch C-CAM RST inverted midrange driver and a 1-inch C-CAM Gold Dome tweeter.



True 3-way design provides rich midrange detail, higher system output, greater power handling, and superior vocal intelligibility and sound localisation.



Optimum imaging and set-up are established via the pivoting IDC, high frequency (+3 dB /0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.



Specification



  • Frequency Response 45 Hz – 30 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 90 dB
  • Maximum SPL 111.6 dBA
  • Power Handling (RMS) 150 W
  • Recommended Amplifier Requirements 30 – 120 W
  • Drive Unit Complement 8" C-CAM cone bass driver, pivoting IDC module housing: 4" C-CAM RST inverted mid range driver 1" C-CAM Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB) Boundary Compensation Switch
  • Overall Diameter (Including Grille) 441 x 288 mm (173/8 x 115/16")
  • Overall Depth (Including Grille) 104 mm (41/8")
  • Mounting Depth 100 mm (315/16")
  • Cut-Out Hole Diameter 387 x 234 mm (151/4" x 93/16")
  • Fixing Type 6 position Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 3.6 kg (7 lb 14 oz)
  • Optional Pre-Construction Bracket WB8 (Green)

£289 each

Monitor Audio W380-IDC



Configured with an 8-inch C-CAM RST bass driver and a pivoting IDC module, housing a 4-inch C-CAM RST inverted midrange driver and a 1-inch C-CAM Gold Dome tweeter.



True 3-way design provides rich midrange detail, higher system output, greater power handling, and superior vocal intelligibility and sound localisation.



Optimum imaging and set-up are established via the pivoting IDC, high frequency (+3 dB /0 dB / -3 dB) level adjustment, and boundary compensation (on / off) controls.



Specification



  • Frequency Response 45 Hz – 30 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 90 dB
  • Maximum SPL 111.6 dBA
  • Power Handling (RMS) 150 W
  • Recommended Amplifier Requirements 40 – 150 W
  • Drive Unit Complement 8" C-CAM cone bass driver featuring RST, pivoting IDC module housing: 4" C-CAM RST inverted mid range driver 1" C-CAM Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB) MF Level Switch (+3 dB / 0 dB / -3 dB) Boundary Compensation Switch
  • Overall Diameter (Including Grille) 441 x 288 mm (173/8 x 115/16")
  • Overall Depth (Including Grille) 104 mm (41/8")
  • Mounting Depth 100 mm (315/16")
  • Cut-Out Hole Diameter 387 x 234 mm (151/4 x 93/16")
  • Fixing Type 6 position Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 4.1 kg (9 lb)
  • Optional Pre-Construction Bracket WB8 (Green)

£364 each

Monitor Audio W150-LCR



The 2-way W150-LCR in-wall model with 5-inch drivers features Monitor Audio's MMP II cones coupled with a pivoting version of our C-CAM Gold Dome tweeter.



These in-wall models can be used vertically or horizontally: the ideal aspect for centre-channel applications in discreet home theatre systems.



Specification

  • Frequency Response 60 Hz – 30 kHz
  • Nominal Impedance 8 ohms
  • Sensitivity (1W@1M) 88 dB
  • Maximum SPL 108 dBA
  • Power Handling (RMS) 100 W
  • Recommended Amplifier Requirements 30 – 100 W
  • Drive Unit Complement 2 x 5" MMP II cone bass driver 1 x 1" (25 mm) C-CAMpivoting Gold Dome tweeter
  • Adjustment Controls N/A
  • Overall Dimensions (Including Grille (H x W x D)) 177.4 x 385.2 mm (7 x 153/16")
  • Overall Depth (Including Grille) 105 mm (41/8")
  • Mounting Depth 100 mm (315/16")
  • Cut-Out Dimensions 145 x 353 mm (53/4" x 137/8")
  • Required Clearance for Doglegs in Centre Configuration 400 x 197mm (153/4" x 73/4")
  • Fixing Type Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 3.76 kg (8.3 lb)
  • Optional Pre-Construction Bracket WB5LCR (Yellow)

£195 each

Monitor Audio W250-LCR



The 2-way W250-LCR in-wall model with 5-inch drivers features Monitor Audio's C-CAM cones coupled with a pivoting version of our C-CAM Gold Dome tweeter.



These in-wall models can be used vertically or horizontally: the ideal aspect for centre-channel applications in discreet home theatre systems.



This model also provides high frequency level adjustment for super-fine audio tuning.



Specification



  • Frequency Response 60 Hz – 30 kHz
  • Nominal Impedance 8 ohms
  • Sensitivity (1W@1M) 88 dB
  • Maximum SPL 108 dBA
  • Power Handling (RMS) 100 W
  • Recommended Amplifier Requirements 30 – 100 W
  • Drive Unit Complement 2 x 5" C-CAM cone bass driver 1 x 1" (25 mm) C-CAM pivoting Gold Dome tweeter
  • Controls High Frequency Level Switch (+3 dB / 0 dB / -3 dB)
  • Overall Dimensions (Including Grille (H x W x D)) 177.4 x 385.2 mm (7 x 153/16")
  • Overall Depth (Including Grille) 105 mm (41/8")
  • Mounting Depth 100 mm (315/16")
  • Cut-Out Dimensions 145 x 353 mm (53/4 x 137/8")
  • Required Clearance for Doglegs in Centre Configuration 400 x 197 mm (15 3/4" x 7 3/4")
  • Fixing Type Tri-Grip dog fixings
  • Construction Material Mineral filled ABS, RoHS compliant
  • Weight 3.76 kg (8.3 lb)
  • Optional Pre-Construction Bracket WB5LCR (Yellow)

£259 each

Monitor Audio CP-WT150



Offering high impact audio and discreet trimless design for smaller environments the entry-level CP-WT150 in-wall model features a 5" MMP II bass driver, high frequency level adjustment (+3 dB / 0 dB / -3 dB) and a pivoting C-CAM tweeter.



Technology

  • Pivoting C-CAM Gold Dome tweeter and MMP II bass driver.
  • High overall efficiency.
  • High frequency level adjustment (+/-3 dB).
  • Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
  • Magnetic and easily removable steel grille.
  • Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
  • Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.

Specification



  • Frequency Response 75 Hz - 25 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 85 dB
  • Maximum SPL 102.8 dBA
  • Power Handling (RMS) 50 W
  • Recommended Amplifier Requirements 20 - 50 W
  • Crossover Frequency 2.8 kHz @ 12 dB / Octave
  • Drive Unit Complement 2-Way 5" MMP II cone bass driver 1" C-CAM  Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB)
  • Overall Dimensions (H x W x D) 360.5 x 242 mm (143/16 x 91/2")
  • Overall Depth (Including Grille) 102 mm (4")
  • Cut-Out Dimensions 326 x 207 mm (1213/16 x 81/8")
  • Mounting Depth 96 mm (33/4")
  • Fixing Type 6 position Tri-Grip dog leg fixings
  • Construction Material Mineral Filled ABS Plastic (RoHS2 Compliant)
  • Connection Gold plated 'push' type terminals
  • Weight 2.65 kg (5 lb 14 oz)
  • Optional Pre-Construction Bracket WB6 (Purple)

£179 each

Monitor Audio CP-WT260



The CP-WT260's pivoting C-CAM tweeter is joined by a 6" C-CAM bass driver - and high frequency level adjustment by a boundary compensation control for optimum bass tuning when positioned near room corners.



Technology

  • Pivoting C-CAM Gold Dome tweeter and C-CAM bass driver.
  • High overall efficiency.
  • High frequency level adjustment (+/-3 dB).
  • Boundary compensation controls.
  • Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
  • Magnetic and easily removable steel grille.
  • Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
  • Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.

Specification



  • Frequency Response 65 Hz - 25 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 88 dB
  • Maximum SPL 106.9 dBA
  • Power Handling (RMS) 65 W
  • Recommended Amplifier Requirements 20 - 65 W
  • Crossover Frequency 2.6 kHz @ 12 dB / Octave
  • Drive Unit Complement 2-Way 6" C-CAM cone bass driver 1" C-CAM pivoting Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB) Boundary Compensation Switch
  • Overall Dimensions (H x W x D) 415 x 262.5 mm (165/16 x 105/16")
  • Overall Depth (Including Grille) 102 mm (4")
  • Cut-Out Dimensions 381 x 228 mm (15 x 9")
  • Mounting Depth 96 mm (33/4")
  • Fixing Type 6 position Tri-Grip dog leg fixings
  • Construction Material Mineral Filled ABS Plastic (RoHS2 Compliant)
  • Weight 3.31 kg (7 lb 4 oz)
  • Optional Pre-Construction Bracket WB8 (Green)
  • Optional Back Box WCBOX-L

£249 each

Monitor Audio CP-WT380



Alongside a pivoting C-CAM tweeter, the CP-WT380 model introduces a powerful 8" C-CAM bass driver featuring the Rigid Surface Technology (RST) cone surface employed by our range-topping home audio speaker systems.



Technology



  • Pivoting C-CAM Gold Dome tweeter.
  • C-CAM bass driver featuring Rigid Surface Technology (RST).
  • High overall efficiency.
  • High frequency level adjustment (+/-3 dB).
  • Boundary compensation controls.
  • Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
  • Magnetic and easily removable steel grille.
  • Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
  • Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.

Specification



  • Frequency Response 50 Hz - 25 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 89 dB
  • Maximum SPL 109.6 dBA
  • Power Handling (RMS) 120 W
  • Recommended Amplifier Requirements 30 - 120 W
  • Crossover Frequency 2.5 kHz @ 12 dB / Octave
  • Drive Unit Complement 2-Way 8" C-CAM RST cone bass driver 1" C-CAM pivoting Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB) Boundary Compensation Switch
  • Overall Dimensions (H x W x D) 472.5 x 303.5 mm (185/8 x 1115/16")
  • Overall Depth (Including Grille) 106 mm (43/16")
  • Cut-Out Dimensions 438 x 269 mm (171/4 x 109/16")
  • Mounting Depth 99 mm (37/8")
  • Fixing Type 6 position Tri-Grip dog leg fixings
  • Construction Material Mineral Filled ABS Plastic (RoHS2 Compliant)
  • Weight 4.95 kg (10 lb 14 oz)
  • Optional Pre-Construction Bracket WB10 (Light Brown)

£359 each

Monitor Audio CP-WT380 IDC



Incorporating Monitor Audio’s innovative, pivoting Inverted Dual Concentric (IDC) midrange/tweeter module and 8" RST C-CAM bass driver, the three-way CP-WT380IDC represents the highest level of new CP performance.



Technology



  • Pivoting IDC C-CAM gold dome tweeter.
  • Pivoting module consisting of IDC midrange driver and C-CAM Gold Dome tweeter.
  • C-CAM bass driver featuring Rigid Surface Technology (RST).
  • High overall efficiency.
  • High frequency level adjustment (+/-3 dB).
  • Midrange frequency level adjustment.
  • Boundary compensation controls.
  • Die-cast aluminium front baffle.
  • Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
  • Magnetic and easily removable steel grille.
  • Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
  • Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.

Specification



Frequency Response 50 Hz - 30 kHz

Nominal Impedance 6 ohms

Sensitivity (1W@1M) 89 dB

Maximum SPL 109.6 dBA

Power Handling (RMS) 120 W

Recommended Amplifier Requirements 30 - 120 W

Crossover Frequency Bass low pass: 300 Hz @ 6 dB / Octave Mid: 300 Hz @  6 dB / Octave
& 3 kHz @ 12 dB / Octave

Drive Unit Complement 3-Way 8" C-CAM RST cone bass driver 4" C-CAM IDC cone mid range driver 1" C-CAM Gold Dome tweeter (tweeter & midrange driver combined in a pivoting module)

Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB) MF Level Switch (+3 dB/ 0 dB/ -3 dB) Boundary Compensation Switch

Overall Dimensions (H x W x D) 472.5 x 303.5 mm (185/8 x 1115/16")

Overall Depth (Including Grille) 106 mm (43/16")

Cut-Out Dimensions 438 x 269 mm (171/4 x 109/16")

Mounting Depth 99 mm (37/8")

Fixing Type 6 position Tri-Grip dog leg fixings

Construction Material Mineral Filled ABS Plastic (RoHS2 Compliant)

Weight 5.62 kg (12 lb 6 oz)

Pre-Construction Bracket WB10 Pre-Construction Bracket (Light Brown)



£359 each

Monitor Audio CP-WT140 LCR



The CP-WT140LCR is a multi-purpose speaker, for portrait or landscape applications as a high performance music or theatre satellite.



Technology

  • Pivoting C-CAM Gold Dome tweeter.
  • 2 x MMP II bass drivers.
  • High overall efficiency.
  • High frequency level adjustment (+/-3 dB).
  • Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
  • Magnetic and easily removable steel grille.
  • Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
  • Airtight enclosure design, which protects each precision-engineered driver system against the
  • damaging ingress of dust and dirt.

Specification

  • Frequency Response 60 Hz - 25 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 88 dB
  • Maximum SPL 108.8 dBA
  • Power Handling (RMS) 100 W
  • Recommended Amplifier Requirements 20 - 100 W
  • Crossover Frequency 2.6 kHz @ 12 dB / Octave
  • Drive Unit Complement 2 x 4" MMP II cone bass driver 1" C-CAM pivoting Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB)
  • Overall Dimensions (H x W x D) 217 x 333 mm (89/16 x 131/16")
  • Overall Depth (Including Grille) 103 mm (41/16")
  • Cut-Out Dimensions 183 x 299 mm (73/16 x 113/4")
  • Mounting Depth 97 mm (313/16")
  • Fixing Type 4 position Tri-Grip dog leg fixings
  • Construction Material Mineral Filled ABS Plastic (RoHS2 Compliant)
  • Weight 2.5 kg (5 lb 8 oz)
  • Optional Pre-Construction Bracket WB4LCR (Dark Brown)

£225 each

Monitor Audio CP-WT240 LCR



The CP-WT240LCR is a multi-purpose speaker, for portrait or landscape applications as a high performance music or theatre satellite.



Technology



  • Pivoting C-CAM Gold Dome tweeter.
  • 2 x C-CAM bass drivers.
  • High overall efficiency.
  • High frequency level adjustment (+/-3 dB).
  • Boundary compensation controls.
  • Our innovative Tri-Grip fixing system is easier to install than conventional clamping schemes but provides three times the surface area and a better surface seal, maximising bass response and mid-range clarity.
  • Magnetic and easily removable steel grille.
  • Paint-able surface to blend with the living environment. Additional scrim material is provided for trouble free painting.
  • Airtight enclosure design, which protects each precision-engineered driver system against the damaging ingress of dust and dirt.

Specification



  • Frequency Response 60 Hz - 25 kHz
  • Nominal Impedance 6 ohms
  • Sensitivity (1W@1M) 88 dB
  • Maximum SPL 108.8 dBA
  • Power Handling (RMS) 100 W
  • Recommended Amplifier Requirements 20 - 100 W
  • Crossover Frequency 2.6 kHz @ 12 dB / Octave
  • Drive Unit Complement 2 x 4" C-CAM cone bass driver 1" C-CAM pivoting Gold Dome tweeter
  • Adjustment Controls HF Level Switch (+3 dB / 0 dB / -3 dB) Boundary Compensation Switch
  • Overall Dimensions (H x W x D) 217 x 333 mm (89/16 x 131/16")
  • Overall Depth (Including Grille) 103 mm (41/16")
  • Cut-Out Dimensions 183 x 299 mm (73/16 x 113/4")
  • Mounting Depth 97 mm (313/16")
  • Fixing Type 4 position Tri-Grip dog leg fixings
  • Construction Material Mineral Filled ABS Plastic (RoHS2 Compliant)
  • Weight 2.5 kg (5 lb 8 oz)
  • Optional Pre-Construction Bracket WB4LCR (Dark Brown)

£299 each

Monitor Audio in-wall Subwoofer

Monitor Audio IWS-10 in-wall Subwoofer



The IWS-10 is specified to produce excellent bass quality in a range of wall, ceiling, even floor locations, ideally but not exclusively with its IWB-10 back box.



The IWS-10 subwoofer driver employs a rigid, flat 10” surface of 10 mm (3/8") RDT material derived from Monitor audio’s acclaimed ‘Platinum’ series of high-end speakers. A large vented pole helps to move air quickly, reducing power compression and increasing heat dissipation.

It features Monitor Audio’s patented Tri-Grip clamping system and paintable trim-less grille and frame edge.



Specification



  • Frequency Response 28 Hz — 120 Hz (when mounted in optimum enclosure)
  • Nominal Impedance 8 ohms
  • Sensitivity (1W@1M) 86 dB
  • Maximum SPL Single unit 109.8 dB; Pair 115.8 dB
  • Power Handling (RMS) 150 W
  • Cut-Out Dimensions 280 x 280 mm (11 x 11")
  • Mounting Depth 89.98 mm (31/2")
  • Fixing Type 4 position Tri-Grip dog leg fixings
  • Connection Gold plated "push" type terminals
  • Construction Material Mineral Filled ABS Plastic (RoHS2 Compliant)
  • Overall Dimensions (H x W x D) 302 x 302 x 92.28 mm (117/8 x 117/8 x 35/8")
  • Overall Dimensions (Including Grille (H x W x D) 314.21 x 314.21 x 100.78 mm (123/8 x 123/8 x 315/16")
  • Weight 3.8 kg (8 lb 6 oz)

£349

Monitor Audio IWB-10 Subwoofer back-box





The IWB-10 is a sealed pre-construction back box, pre-wired with external terminals, for the IWS-10 subwoofer.



Having an internal volume of 16.5 litres, the IWB-10 is designed to fit between standard 14" stud spacing and comes supplied with adjustable steel fixing brackets. While providing the ideal environment for the driver, the IWB-10 will also reduce the radiation of sound to adjacent rooms.



Specification



  • External Dimensions (H x W x D) 850 x 351 x 85 mm (331/2 x 1313/16 x 311/32")
  • Construction Material MDF (CARB level 2 approved)
  • Internal Volume 16.5 L
  • Weight 6.82 kg (15 lb)

£149



Monitor Audio IWA-250 Amplifier



The IWA-250 switch mode amplifier is a slim, powerful dedicated design in a heavy-duty 1U rack mount case.



Delivering up to 250 watts into 4 ohms, a single IWA-250 will power single or dual IWS-10's to provide higher power levels for larger rooms or to meet customer demands.



Technology



  • Rigid, high quality steel case
  • Switch mode power supply
  • Class D power amplifier delivering up to 250 watts into 4 ohms (dual IWS-10 drivers)
  • High efficiency design resulting in cool running – low thermal output
  • DSP controlled with advanced limiters
  • <0.5watt standby power consumption (ErP certified)
  • DC short circuit protection, over-current and thermal protection

£349

Print Print | Sitemap
© midsat ltd

Call
