OUTDOOR & WEATHERPROOF SPEAKERS

Monitor Audio Outdoor & Weatherproof speakers

Monitor Audio AWC265



Developed using all C-CAM driver systems derived from our critically acclaimed hi-fi speakers, the new AWC265 comprises a stylish two-way 6 1/2” C-CAM bass driver.


Technology

  • Quick and easy installation
  • High Performance C-CAM bass and high frequency drivers
  • Stainless Steel ‘Trimless’ grille – strong and resistant to corrosion and sprayable
  • Non-ferrous Samarium Cobalt magnets for grille attachment – prevent rust and corrosion
  • IP55 certified for extreme climate conditions: Salt Spray, UV stability, Water, Vibration, Anti-corrosion
  • Patented Tri-grip Dog-leg fixings for easy, long-lasting installation
  • EPDM barriers to prevent moisture. EPDM is an extremely durable synthetic rubber membrane (ethylene propylene diene monomer)
  • Gold plated push terminals with silicon cover
  • Stainless fixing screws with Silicone covers
  • Tweeter level attenuation (internal) – set prior to installation
  • Applications: pool rooms, bathrooms, marine deck, universal outdoor installation

£225

Monitor Audio AWC265-T2



Anodised black for stealthy in-wall/ceiling integration, the C-CAM bass drivers combine co-axially with Monitor Audio’s renowned 1" C-CAM tweeters, which are twinned and angled on the AWC265-T2 to deliver high performance stereo sound from a single unit where space is limited.



Technology

  • High Performance C-CAM bass and high frequency drivers
  • Stainless Steel ‘Trimless’ grille – strong and resistant to corrosion and sprayable
  • Non-ferrous Samarium Cobalt magnets for grille attachment – prevent rust and corrosion
  • IP55 certified for extreme climate conditions: Salt Spray, UV stability, Water, Vibration, Anti-corrosion
  • Patented Tri-Grip Dog-Leg fixings for easy, long-lasting installation
  • EPDM barriers to prevent moisture. EPDM is an extremely durable synthetic rubber membrane (ethylene propylene diene monomer)
  • Gold plated push terminals with silicon cover
  • Stainless fixing screws with Silicone covers
  • Tweeter level attenuation (internal) – set prior to installation
  • Applications: pool rooms, bathrooms, marine deck, universal outdoor installation

£300

Monitor Audio AWC280



Developed using all C-CAM driver systems derived from our critically acclaimed hi-fi speakers, the new AWC280 comprises a stylish two-way 8” C-CAM bass driver.



Technology

  • Quick and easy installation
  • High Performance C-CAM bass and high frequency drivers
  • Stainless Steel ‘Trimless’ grille – strong and resistant to corrosion
  • Non-ferrous Samarium Cobalt magnets for grille attachment – prevent rust and corrosion, sprayable
  • IP55 certified for extreme climate conditions: Salt Spray, UV stability, Water, Vibration, Anti-corrosion
  • Patented Tri-grip Dog-leg fixings for easy, long-lasting installation
  • EPDM barriers to prevent moisture. EPDM is an extremely durable synthetic rubber membrane (ethylene propylene diene monomer)
  • Gold plated push terminals with silicon cover
  • Stainless fixing screws with Silicone covers
  • Tweeter level attenuation (internal) – set prior to installation
  • Applications: pool rooms, bathrooms, marine deck, universal outdoor installation

£300

Monitor Audio AWC280-T2



Anodised black for stealthy in-wall/ceiling integration, the C-CAM bass drivers combine co-axially with Monitor Audio’s renowned 1" C-CAM tweeters, which are twinned and angled on the AWC280-T2 to deliver high performance stereo sound from a single unit where space is limited.



Technology

  • High Performance C-CAM bass and high frequency drivers
  • Stainless Steel ‘Trimless’ grille – strong and resistant to corrosion
  • Non-ferrous Samarium Cobalt magnets for grille attachment – prevent rust and corrosion
  • IP55 certified for extreme climate conditions: Salt Spray, UV stability, Water, Vibration, Anti-corrosion and sprayable
  • Patented Tri-grip Dog-leg fixings for easy, long-lasting installation
  • EPDM barriers to prevent moisture. EPDM is an extremely durable synthetic rubber membrane (ethylene propylene diene monomer)
  • Gold plated push terminals with silicon cover
  • Stainless fixing screws with Silicone covers
  • Tweeter level attenuation (internal) – set prior to installation
  • Applications: pool rooms, bathrooms, marine deck, universal outdoor installation

£375

Monitor Audio V240 - Black or White





Thanks to Monitor Audio’s heritage in high end audio, the Vecta V240 indoor and outdoor speaker has been engineered to the highest possible standard, and will deliver top quality performance for a true audio experience.



The stylish, compact and versatile Monitor Audio Vecta V240 speaker cleverly combines architectural aesthetics with innovation and the high quality professional audio performance that the company is renowned for.



The Vecta V240 offers incredible versatility and simple installation. Using cleverly designed brackets and a single point automatic connection system, Vecta can be quickly and easily mounted horizontally or vertically. Installers fix the bracket to the wall, and then simply drop the speaker in place and secure with a single screw. Not only does this installation method save integrators’ time, but it also simplifies the complexity of installing speakers at height or at difficult angles.  An automatic connection system means that the install is extremely sleek, with no wires visible. To ensure clients receive the best audio possible, when mounted to the wall bracket, Vecta can be angled by 25 degrees or tilted a further 32.5 degrees (using the optional wedge) to direct the audio to the desired location.



When installing speakers outside, a different approach is required, as these systems need to be capable of delivering a high quality audio standard in external conditions and locations. For the Vecta V240, Monitor Audio has mounted dual 4" C-CAM metal cone drives to the curved baffle to ensure a controlled sound field is delivered. This minimises ceiling or wall reflections when mounted under eaves or in a corner, while still being wide enough for superior coverage when wall-mounted. The centrally mounted Gold C-CAM tweeter is horn loaded to ensure dispersion at the crossover point matches the mid-range, providing a smooth off axis frequency response. This approach results in the ultimate audio experience, with fewer audio black spots.



The aesthetics match the performance of this speaker, as Monitor Audio has paid close attention the design. Developed with a curved tapered back cabinet in black or white, the Vecta V240 blends seamlessly under eaves or in vertical corners.  The speakers are cased in a high-density ABS enclosure with rust proof grille that is designed to withstand extreme environmental exposure. The completely sealed box cabinet is free from air noise or potential ingress of water and dirt, which helps to maintain the IP55 environmental protection rating.



Key Features



  • Stylish, compact, and versatile architectural ‘All-weather’ design
  • Dual 4" Drivers featuring C-CAM metal cone technology
  • 25 mm (1") Gold C-CAM Dome tweeter
  • Sealed enclosure impervious to ‘all weather’ environments – Rated to IP55
  • Intelligent automatic connection system – easier to install with no visible wires.
  • Straight wall mount bracket V-MOUNT – Providing 25 degrees tilt (optional wedge adds extra 32.5 degrees)
  • Corner bracket V-CORNER for corner or under eave installation
  • High-density ABS enclosure with rust proof grille
  • Available in black or white
  • Paintable to match a custom installation

£249

Monitor Audio CL50 (PAIR)





2-Way outdoor IP55 rated satellite speaker, housing a single 5" C-CAM® bass driver and a 1" C-CAM gold dome tweeter.



Features:



  • Quick and easy installation
  • High performance C-CAM tweeter and driver technology
  • Robust solid sealed, high density polypropylene enclosure - UV rated.
  • Full installation flexibility: 175º rotational bracket, (it also features angled sections and screw holes to provide corner fixing.)
  • 15º angled wedge supplied for additional bracket versatility
  • Anchor point for security chain attachment
  • ABR (Auxiliary Bass Radiator) for added low frequency punch
  • Aluminium grilles prevent rust
  • Textured white and black finish, paintable to suit décor (paint mask supplied)
  • Rotational 'M' logo to align with portrait or landscape positions.

£249

Monitor Audio CL60 (PAIR)





2-Way outdoor IP55 rated satellite speaker, housing a single 6 1/2" C-CAM® bass driver and a 1" C-CAM gold dome tweeter.



Features:



  • Quick and easy installation
  • High performance C-CAM tweeter and driver technology
  • Robust solid sealed, high density polypropylene enclosure - UV rated.
  • Full installation flexibility: 175º rotational bracket, (it also features angled sections and screw holes to provide corner fixing.)
  • 15º angled wedge supplied for additional bracket versatility
  • Anchor point for security chain attachment
  • ABR (Auxiliary Bass Radiator) for added low frequency punch
  • Aluminium grilles prevent rust
  • *Textured white and black finish, paintable to suit décor (paint mask supplied)
  • Rotational ‘M' logo to align with portrait or landscape positions.

£349

Monitor Audio CL80 (PAIR)



2-Way outdoor IP55 rated satellite speaker, housing a single 8" C-CAM® bass driver and a 1" C-CAM gold dome tweeter.



Features:



  • Quick and easy installation
  • High performance C-CAM tweeter and driver technology
  • Robust solid sealed, high density polypropylene enclosure - UV rated.
  • Full installation flexibility: 175º rotational bracket, (it also features angled sections and screw holes to provide corner fixing.)
  • 15º angled wedge supplied for additional bracket versatility
  • Anchor point for security chain attachment
  • ABR (Auxiliary Bass Radiator) for added low frequency punch
  • Aluminium grilles prevent rust
  • *Textured white and black finish, paintable to suit décor (paint mask supplied)
  • Rotational ‘M' logo to align with portrait or landscape positions

£449

Monitor Audio CLG140



The CLG140 satellite speaker is a robust high sensitivity design built to deliver richly detailed hi-fi quality mid/high frequencies.



Engineered to withstand the most extreme temperatures and weather conditions, its rigid conical polymer enclosure houses the company’s signature 1” (25 mm) C-CAM Gold Dome tweeter co-axially aligned with a 4" MMP bass-mid driver. The horn-shaped housing provides excellent audio directivity in free air conditions when positioned close to the garden surface on a bracket/spike assembly, which neatly encapsulates and channels the connecting cable into the ground for a discreetly installed result. Alternatively it’s possible to mount the CLG140 on a tree, pole, wall or fence.



Supplied in a durable dark brown finish for excellent coordination with garden colours, the CLG140’s casing can be painted to blend with any environment.



Technology



  • 4" MMP II bass-midrange driver
  • Coaxially aligned 25 mm C-CAM Gold Dome tweeter
  • Optimised for high sensitivity and wide dispersion
  • Internal matching transformer for 70/100 V line level operation
  • Designed to operate under extreme climatic conditions from -20 to 70 C
  • Rigid, high impact polymer cabinet for long life and durability
  • Bracket mounting made from die-cast aluminium alloy
  • Garden spike (CLG-SPIKE R) and mount (CLG-MOUNT) available separately
  • Certified to IP55 rating
  • Encapsulated cable runs inside bracket and spike for discreet appearance
  • Dark Brown finish blends with garden colours, but enclosure is paintable to blend with alternative settings
  • Applications include garden and deck areas: system expands with garden size
  • PTC protection against power overload



£249

Monitor Audio CLG160



Suitable for ground level installation within the garden and around decking areas or mounted onto a tree, pole or garden fence, the new CLG160 speaker features a rigid polymer shell which ensures it is resilient to extreme weather conditions.



Installation is simple, thanks to the requirement for the speaker to be wired in a mono configuration and powered by one amplifier channel. The other amplifier channel can be used to power the subwoofer. This configuration allows the levels between bass and mid-high range to be easily equalised. Alternatively, the system can be designed to provide stereo operation if desired by creating stereo left/right zones.



Despite being installed outside, the aesthetics of the speakers are just as important. Finished in dark brown, the CLG160 blends seamlessly into this environment to provide high quality sound for outdoor entertainment, whilst not distracting from the landscape. The speaker casing can be painted a different colour, if required.



Technology



  • Purposely designed 6" MMP II bass-mid range driver
  • 25 mm C-CAM Gold Dome tweeter – coaxially mounted
  • 70/100v line level operation –internal matching transformer
  • Tree or pole mounting possible with additional fixings
  • Garden spike (CLG-SPIKE R) and mount (CLG-MOUNT) available separately
  • PTC overload protection against power overload

£325

Monitor Audio CLG-W12 Subterranean Sub



The CLG-W12 is a passive subwoofer. Optimised for discreet sub-surface installation, its proprietary Monitor Audio bandpass design incorporates an internally loaded 12" C-CAM driver which sits in a waterproof rotationally-moulded polymer enclosure buried below the garden surface - only the CLG-W12’s domed output port is visible.



From this little ‘chimney’ powerfully taut bass frequencies will join the clean mids and highs of the surrounding CLG140/CLG160 satellites for punchy and articulate full-range garden sound.



The CLG-W12 can be powered from a single amplifier channel at 4 ohms, with its 70/100 V line option recommended for cable runs over 10m (30ft) and for adding subwoofers to the system. In this line configuration, the CLG140/CLG160 satellites are daisy-chained to the CLG-W12, one after the other, up to a recommended maximum of twelve per subwoofer. System expansion to larger garden spaces simply involves the addition of amplifier channels, subwoofers and satellites.



In the simplest designs, satellites are connected in a mono configuration to one amplifier channel, the other channel powering the subwoofer. The use of a stereo power amplifier with 70/100volt line capability and crossover features will allow the adjustment of levels between bass and mid-high range. Alternatively, the system can be designed to provide stereo operation by adding elements to create left/right zones.



When installed the Climate Garden System delivers a smooth, wide-open and controlled frequency response from 30 Hz to 30 kHz in the targeted environment: better than many home audio systems! For patio or deck applications, the CLG-W12 will install within a planter box to enhance Monitor Audio’s CL Series all-weather cabinet speakers with deep bass frequencies, giving custom installers additional design options.



Technology



  • Below ground garden installation. On patios or decks will install within a suitably sized planter
  • Extended response down to 30 Hz
  • Long throw 12" sub-woofer driver featuring C-CAM cone technology and rigid die-cast chassis
  • Bandpass cabinet enclosure delivers high efficiency and punchy, extended bass
  • 70/100 V and 4 ohm tap for flexible system design: additional units can be added and ‘daisy-chained’ together
  • Robust moulded cabinet: strong and waterproof with fewer joints to compromise structural integrity
  • Certified to IP54 Ingress Protection rating
  • Dark brown finish blends with garden colours
  • Applications: garden, deck and patio, theme parks
  • 5 year warranty

£1495

QAcoustics Weatherproof outdoor speakers

Q-Install QI45EW 4.5” On-Wall Speaker





The Qi 45 is an attractive and compact wall mounted two-way speaker system ideally suited to both indoor or outdoor environments.



Featuring a tough UV resistant ABS enclosure and aluminium speaker grille the Qi45 is designed to provide many years of trouble free service whatever the weather. Its diminutive dimensions and versatile mounting bracket make it both easy to install and the perfect solution to providing music in many applications; including outdoor dining and restaurant areas and indoor public spaces and conference facilities.



Q Acoustics engineers have carefully crafted the Qi 45's audio performance to deliver an exceptional combination of clarity and focused power using a rigid polypropylene driver cone, high quality crossover network and bass reflex enclosure to deliver results that comfortably exceed expectations.



Specification:



  • Tweeter:0.5" PEI dome
  • Sensitivity: 86 dB/1W
  • Impedance (nominal) ohms: 8ohm
  • Dimensions (w x h x d): 135mm x 245mm x 170mm (inc. bracket)
  • Bracket hole spacing: 70mm
  • Woofer: 4.5" Polypropylene
  • Power handling: 10 W to 50 W
  • Frequency response: 85 Hz to 20 kHz
  • Available in White and Black
  • Warranty: 5 Years

£135 single speaker

Q-Install QI65EW 6.5" On-Wall Speaker





Q Acoustics engineers have carefully crafted the Qi 65’s audio performance to deliver an exceptional combination of clarity and focused power.



Using a rigid polypropylene driver cone, high quality crossover network and bass reflex enclosure, they deliver results that comfortably exceed expectations.


Specification:



  • Tweeter: 1" AL dome
  • Sensitivity: 87 dB/1W
  • Impedance (nominal) ohms: 8ohm
  • Dimensions (w x h x d): 325mm x 225mm x 180mm (inc. bracket)
  • Bracket hole spacing: 70mm
  • Woofer: 6.5" Polypropylene
  • Power handling: 15 W to 80 W
  • Frequency response: 80 Hz to 20 kHz
  • Available in White and Black
  • Warranty: 5 Years

£195 single speaker

Q-Install QI65LW Outdoor Rock Speaker





The Qi 65 is the perfect speaker for those who want to create music in a landscaped environment.



Finished in a granite effect texture and incorporating a wide range 6.5" woofer and 1" tweeter the Qi 65 can all but disappear from conscious view when positioned within outdoor areas such as bordered patios and alpine gardens. Its rugged glass reinforced polymer cabinet construction and weatherproof cable termination allow the Qi 65 to be located at ground level making it easy to locate and install with confidence.



Q Acoustics have engineered a low resonance cabinet and optimized the driver characteristics to ensure the Qi 65 delivers a full and clear sound even at high volumes, making is ideal for high quality outdoor music reproduction, announcements or even atmospheric birdsong!



Specification:



  • Tweeter:1" PEI dome
  • Woofer: 6.5" Polypropylene
  • Power handling (program): 10-60W
  • Impedance (nominal) ohms: 8ohm
  • Sensitivity: 88db/1W
  • Frequency response: 70 Hz to 20 kHz
  • Dimensions (w x h x d): 330mm x 280mm x 240mm
  • Warranty: 5 Years

£249
